Purpose of Machine Tool:
KST-SG series CNC Spinning Machine (single roller) is especially developed to spin lamps, ventilations，art wares， kitchenwares and auto fittings. It has many patents issued by the State Intellectual Property Office. This machine is practical, professional and strong. It has high production efficiency and can complete horn, bucket, cone type, parabolic products. It can also process threading, trimming, flanging and rolling at the same machine tool. The machine can spin many materials such as steel, alloy and copper etc. It has solved the traditional problems such as lack of skilled workers. With advanced digital control, it is easy to operate. The machine can improve the production efficiency, machining accuracy and saving the cost of human resources. It is the ideal processing machine for light, automobile, military, mechanic and other manufacturing industries.
Standard Configurations & Main Features:
GSK 980TDc as standard CNC system which has USB port.
Meehanite cast iron after aging treatment, with high quality and less deformation.
Adopted independent spindle unit to ensure good movement precision, stiffness and stability.
Precision ball screws ensure dynamic performance well and positioning accurately.
Feeding axles are controlled by servo motors.
Spindle motor is Servo controlled.
Pneumatic tailstock.
Integrated automatic lubrication system makes the maintenance more reliable.
Configuration cooling pump.
Mobile manual pulse generator makes easy to operate.
Semi-enclosed shield.
Optional Accessories (Extra Price):
◇ NC system such as FANUC，SIEMENS，GSK or KND is available for your selection.
◇ Hydraulic tailstock.
|
Model |
KST-SG300 |
KST-SG500 |
|
Amount of Rollers |
1+ |
1+ |
|
Max. Diameter of Material |
Ø300 mm |
Ø500 mm |
|
Max. Swing Over Slide |
＜Ø300 mm |
＜Ø500 mm |
|
Max. Length of Work Piece |
200 mm |
300 mm |
|
Thickness of Work Piece |
0.5-3.0 mm (Aluminum, Copper) 0.5-2.2 mm (Carbon Steel) 0.5-2.0 mm (Stainless Steel) |
0.5-4.0 mm (Aluminum, Copper) 0.5-3.2 mm (Carbon Steel) 0.5-2.0 mm (Stainless Steel) |
|
X Travel |
300 mm |
300 mm |
|
Z Travel |
220 mm |
320 mm |
|
Pushing Force for X Axis |
30 kN |
30 kN |
|
Pushing Force for Z Axis |
30 kN |
30 kN |
|
Pushing Force of Tailstock |
20 kN |
20 kN |
|
Guide Rail Type |
Linear Guide Rail |
Linear Guide Rail |
|
Width of Bed |
320 mm |
320 mm |
|
Rapid Traverse X/Z |
12/16 m/min |
12/16 m/min |
|
Servo Power X/Z |
6/7.5 N.m |
7.5/10 N.m |
|
Pulse Equivalent X/Z |
0.001 mm |
0.001 mm |
|
Positioning Accuracy |
0.015 mm |
0.010 mm |
|
Repetitive Positioning Accuracy |
0.006 mm |
0.006 mm |
|
Spindle Nose |
C6 |
C6 |
|
Taper of Spindle Bore |
MT6 |
MT6 |
|
Spindle Bore |
Ø52 mm |
Ø52 mm |
|
Spindle Speed |
3000 rpm |
2500 rpm |
|
Taper of Tailstock Quill |
MT5 |
MT5 |
|
Travel of Tailstock |
250 mm |
250 mm |
|
Travel of Tailstock Quill |
200 mm |
200 mm |
|
Diameter of Tailstock Quill |
Ø82 mm |
Ø82 mm |
|
Amount of Tools / Shank Size |
6 / 25×25 mm2 |
6 / 25×25 mm2 |
|
Spindle Motor Power |
5.5 kw |
7.5 kw |
|
Machining Accuracy |
It 6 |
It 6 |
|
Surface Roughness |
Ra 1.25 |
Ra 1.25 |
|
Overall Dimensions |
2.3×1.3×1.6 m3 |
2.5×1.3×1.6 m3 |
|
Net Weight |
2500 kg |
3000 kg |
