Kingston Brand Ram Milling Machine XL6430
Specification
|
Specifications |
Unit |
XL6430 |
|
Table size |
mm |
1270*300 |
|
T-slots(NO./width/pitch) |
mm |
3*14*80 |
|
Max table travel - X/Y/Z |
mm |
720/300/400 |
|
Spindle taper |
- |
7:24 ISO40 |
|
Max rotary angle of table |
|
- |
|
Distance between spindle center line and table surface |
mm |
75-475 |
|
Distance between spindle nose and table surface |
mm |
260-660 |
|
Distance from horizontal spindle center line to arm surface |
mm |
180 |
|
Spindle speed range |
r.p.m |
(V)11 steps 45-1660; (H)12 steps 35-1500 |
|
Arm travel |
mm |
400 |
|
Table feed(X/Y/Z) |
mm/min |
XY:30-830 Z:23-625 |
|
Table rapid speed |
|
1335/1335/1000 |
|
Main motor power |
Kw |
2.2（V）/ 3（H） |
|
Torque of X/Y/Z axis AC servo motor |
Nm |
10 |
|
Cooling pump motor power |
W |
40 |
|
Flow of cooling pump |
L/m |
12 |
|
Overall size |
mm |
1720*1680*1860 |
Standard Accessories
|
No. |
Name |
Detail |
Qua. |
|
1 |
Milling machine |
|
1 |
|
2 |
ISO40 sets milling chuck |
7：24 ISO40 4、5、6、8、10、12、14、16 |
1 |
|
3 |
Taper shank sets milling cutter arbor |
7:24 ISO40-Φ27 |
1 |
|
4 |
Draw bar |
M16(vertical, horizontal) |
1 |
|
5 |
Machine vise |
QB136 |
1 |
|
6 |
Allen Wrench |
5、6、10、12 |
1 |
|
7 |
Double-ended wrench |
17*19 |
1 |
|
8 |
Double-ended wrench |
22*24 |
1 |
|
9 |
Double-ended wrench |
32*36 |
1 |
|
10 |
milling cutter arbor |
Φ27 |
1 |
|
11 |
Nut |
M16 |
2 |
|
12 |
Washer |
16 |
2 |
|
13 |
Operation manual |
|
1 |
|
14 |
Certification |
|
1 |
|
15 |
Packing list |
|
1 |
Optional Accessories
|
NO. |
Name |
|
1 |
CE Schneider electric |
|
2 |
Aluminum hangarm |
|
3 |
3-axis DRO |
|
4 |
Spindle cover |
|
5 |
Worktable cover |
|
6 |
LED work lamp |
|
7 |
Bakelite handwheel |
